Airmar’s entry-level B117 features a single, 50/200 kHz, dual-frequency, ceramic element in a low-profile bronze housing. The nearly-flush design minimizes drag with only 5 mm (3/16″) extending outside of the hull.
B117 Bronze 0° Depth & Temp with Ray Connector for CP370 & DSM300
The B117 features our 50/200 kHz, dual-frequency, single ceramic element in a low-profile housing. The nearly-flush design minimizes drag with only 5 mm (3/16″) extending outside of the hull. The plastic P319 and stainless steel SS60 models are also available to accommodate all hull materials.
Features:
Bronze Housing
Depth and Temperature Only
Usable Shaft Length: 66.5 mm (2.62”)
Replacement nut—405
10 m (33’) cable length
Boat Size: 8 m (25’) and up
Ideal for center-console and trailered boats
Frequency: 50/200 kHz
Maximum Depth Range:
50 kHz: 800-1200 ft
200 kHz: 400-700 ft
Cone: 50 kHz—45°, 200 kHz—12°
RMS Power: 600 W
This product may not be returned to the original point of purchase.Please contact the manufacturer directly with any issues or concerns.
B117 has 0° depth and temperature bronze color for ray connectors of CP370 and DSM300. B117 has our 50/200 kHz dual frequency single ceramic element in a thin housing. The nearly flush design enables…
Depth only or depth and fast-response water-temperature sensing
600 W of power
Dual-frequency element:
50 kHz with a wide 45° beamwidth for depth performance to 353 m (1200′)
200 kHz with a 12° beamwidth for depth performance to 206 m (700′)
Right-angle cable exit saves space and protects transducer if stepped on
Included rubber washer allows tightening of the hull nut to irregular hull surfaces
Low-profile, bronze housing has minimal drag
Plastic (P319) and stainless steel (SS60) models are also available to accommodate all hull materials
